 Product description:
Fiber blanket is reinforced acupuncture technique of fiber blanket, the process does not contain any bond or other ingredients, through enhancing needle-punched process improve the degree of fiber interweave and corresponding blanket delamination resistance, in does not affect its flexible at the same time, make its have good tensile strength. Installation method is simple, accelerated the construction speed of furnace lining highly.
Second, the product features:
Low coefficient of thermal conductivity, easy processing, installation, low thermal capacity, good sound-absorbing properties, excellent chemical qualitative Cain, air flow scouring, thermal shock resistance, corrosion resistance, fiber has good elasticity, high temperature within narrow, anchoring, convenient installation
Three, product and application:
Mainly used for all kinds of industrial furnace and heat pipe the whole fiber lining. Typical applications are as follows: metallurgical machinery, heating furnace, heat treatment furnace, ladle heat preservation cover; Petrochemical industry: conversion furnace, atmospheric and vacuum furnace, furnace, flue; Ceramic electric porcelain: roller kiln, shuttle kiln, tunnel kiln; Other: all kinds of industrial furnace, and hot air pipe, high temperature equipment high temperature furnace lining, etc.
Four, product physical and chemical indicators:
| project/name | T-1000 Fiber blanket | T-1260 Fiber blanket | T-1400 Fiber blanket | T-1430 Fiber blanket | T-1500 Fiber blanket | T-1600 Fiber blanket | | Classification Temperature (¡æ) | 1000 | 1260 | 1400 | 1430 | 1500 | 1600 | | Melting point (¡æ) | 1760 | 1760 | 1760 | 1700 | 1700 | 1840 | | color | white | white | white | white | white | white | | Bulk density kg/m3 | 96-160 | 96-160 | 96-160 | 96-160 | 96-128 | 96-150 | | Tensile strength (MPa) | 0.04 | 0.04 | 0.04 | 0.04 | 0.035 | 0.04 | | Linear shrinkage (%) | (1000¡æx24h)1.5-4 | (1150¡æx24h)1.3-3 | (1200¡æx24h)1.5-3 | (1200¡æx24h)1.5-3 | (1300¡æx24h)2-4 | (1500¡æx24h)~0.5 | | chemical component% | | Al2O3 | 44 | 46-47 | 52-55 | 35 | 45 | 72-75 | | SiO2 | 52 | 51-52 | 44-47 | 49 | 50 | 25-28 | | Gr2O3 | - | - | - | - | 3-5 | - | | ZrO2 | - | - | - | 15 | - | - | | Fe2O3 | <1.0 | 0.2 | 0.2 | 0.2 | - | - |
Note: technical data of the products is by testing standards adopted by the average, will be within a certain range of fluctuation, the data do not represent the quality of the product to ensure the data.
Five, the commonly used specifications of products:
7200 3600 x610x50mm x610x20/25 mm |
