 Product description:
Tube with a loose cotton and inorganic binder wet vacuum suction pressure molding, the product has excellent characteristics of low density and high strength at the same time, it is a kind of multi-purpose products, can be applied to circular tube hot flame resistant and high temperature air directly impact, improve its service life.
Second, the product features:
High temperature stability, low thermal conductivity, low thermal capacity, thermal shock, erosion resistance, easy processing and cutting performance and precision of thickness and size, good resistance to fire and air scour, installation is convenient to use
Three, product application:
Can be applied to require tough at the same time, the bearing and heat insulation, it has good mechanical performance.
Four, product physical and chemical indicators:
| Project/name | T-100tube | T-1260 tube | T-1400 tube | T-1430 tube | T-1600 tube | T-1700tube | T-1800 tube | | Classification Temperature (¡æ) | 1000 | 1260 | 1400 | 1430 | 1600 | 1700 | 1800 | | Bulk density (Kg/m3) | 300-600 | 300-600 | 300-600 | 300-600 | 300-600 | 500-700 | 500-700 | | Linear shrinkage (%) | (800¡æx24h)<1 | (1050¡æx24h)<1 | (1200¡æx24h)<1 | (1200¡æx24h)<1 | (1500¡æx6h)<1 | (1600¡æx6h)<1 | (1700¡æx6h)<1 | | chemical component % | | Al2O3 | 38 | 42 | 50 | 35 | 68 | 80 | 85 | | Al2O3+SiO2 | 96 | 98 | 99 | 84 | 99 | 99.5 | 99.8 | | Fe2O3 | 0.2 | 0.2 | 0.2 | - | - | - | - | | ZrO2 | - | - | - | 15 | - | - | - |
Note: technical data of the products is by testing standards adopted by the average, will be within a certain range of fluctuation, the data do not represent the quality of the product to ensure the data.
Five, the commonly used specifications of products:
According to the users to customize or by my company to design and production. |
